Name: AC Infinity AXIAL 9225, Muffin 120V AC Cooling Fan, 92mm x 92mm x 25mm
SKU: 380053

Description

Designed for projects that require cooling or ventilation; or as a replacement fan for various products.

Includes a heavy-duty aluminum fan with a power plug cord, two fan guards, and a mounting screw set.

UL-certified fan with dual-ball bearings has a lifespan of 67,000 hours and can be mounted in any direction.

High Speed: This model is designed to maximize airflow and may be too loud for some applications.

92 x 92 x 25 mm (3.6 x 3.6 x 1.5 in.) | 100 to 120V AC | Airflow: 37 CFM | Noise: 37 dBA | Speed: 2900 RPM

The heavy-duty axial fan kit is designed for custom projects and as a replacement fan. The fan runs on 100 to 120V AC and contains everything needed to easily mount the fan and power it through a wall outlet. It includes a 4-foot power cord that can be easily attached to the fan's metal terminals and allows it to be powered through a wall outlet. The plug cord can also be cut and converted into lead wires to be connected to a wired AC power source. It also includes two 92 millimeter metal fan guards and a mounting screw set. The AC Infinity axial fan is UL recognized under certificate E503903 and is also CE and RoHS certified.

The fan's housing is constructed of die-cast aluminum painted black and is able to perform well in harsh environments and withstand shocks. Its impeller and blades are molded with thermoplastic, which have a high resistance to flammability. Impedance protected motors contain windings that have a higher resistance to heat during a rotor lock. The fans contain long-life dual ball bearings, allowing them to run continuously for 67,000 hours and be mounted in any direction.

This high-speed fan is suitable for applications where maximizing airflow is the primary objective and a louder noise level is tolerable. Popular uses include casino machines, chicken coops, industrial machinery, arcade systems, and more. Because this is a standard industrial-size fan, it can be used to replace fans found in various electronics and machinery.

Specifications

Product Identification

Manufacturer: AC Infinity Inc.

Product Name: AXIAL 9225

Product Model: HS9225A-X

UPC Code: 854759004228

Product Dimensions

Total Dimensions: 3.6 x 3.6 x 1 in. (9.0 x 9.0 x 2.5 cm)

Hole to Hole Distance: 3.25 x 3.25 in. (8.3 x 8.3 cm)

Screw Hole Size: Ø 0.17 in. (Ø 0.4 cm)

Cord Length: 48 in. (4 feet)

Product Performance and Technical Specs

Fan Model: HS9225A

Total Airflow: 37 CFM

Total Noise: 37 dBA

Speed: 2900 RPM

Operating Voltage: 100 to 120V AC

Power: 11 W

Current: 0.1 A

Static Pressure: 6.4 mm-H2O

Operating Humidity: 35 to 85% RH

Operating Temperature: 32 to 140°F

Fan Bearings: Dual Ball

Mounting Positions: Horizontal or Vertical

L10 Life Expectancy: 67,000 Hours
